A complete OpenCore EFI configuration for Intel-based Hackintosh systems
Specification | Compatibility | Installation | Guides | Credits
| Component | Model |
|---|---|
| CPU | Intel i9-13900K (24) @ 3.20GHz |
| Motherboard | ROG MAXIMUS Z790 HERO |
| RAM | 32GB (2x 16GB) Kingston FURY @ 5200MHz |
| Audio Chipset | ALC4082 |
| GPU | AMD Radeon RX 570 4GB |
| OS Disk (SSDM2) | SSD Kingston NV2 M.2 2280 NVMe PCIe |
| WiFi & Bluetooth | Intel AX210 / BCM4350C2 (working bt only) |
| macOS Version | 15.3.2 (24D81) x86_64 |
| OpenCore Version | 1.0.3 |
| SMBIOS | MacPro7,1 |
- High Sierra (10.13.x)
- Mojave (10.14.x)
- Catalina (10.15.x)
- Big Sur (10.16/11.4)
- Monterey (12.1)
- Ventura (13.5)
- Sonoma (14.0)
- Sequoia (15.x)
- Make your USB installer with this guide
- Clone the repository and paste "BOOT" and "OC" directories into your's pendrive "EFI" folder
- Download GenSMBIOS to generate unique SMBIOS information. Run it and select Generate SMBIOS, as the model select MacPro7,1.
- Open config.plist with ProperTree and go to PlatformInfo > Generic. Set
MLB (Board Serial), SystemSerialNumber (Serial) and SystemUUID (SmUUID) to generated values. Change ROM to your
network card's MAC address without the
:character. **How to get MAC Address? ** - Boot it!
⚠️ IMPORTANT: You CAN NOT use SMBIOS from this repository, it MUST be unique for every macOS installation
If you have any problems with installation or booting your macOS, kernel panics or another system related issue check
OC configuration guide
If something else isn't working properly (for example USB ports, iServices, DRM/Netflix) check Post-Install guide
- Creating USB installer: *click*
- OpenCore configuration: *click*
- Post-Install: *click*
- Troubleshooting: *click*
- ACPI patching: *click*
- USB mapping: *click*
- [Bootloader] OpenCore
- [Driver] OpenRuntime
- [Driver] HFSPlus
- [Kext] Lilu
- [Kext] VirtualSMC
- [Kext] WhateverGreen
- [Kext] AppleALC
 |
|---|
